Filter sizes for Canon EF lenses

Canon filter sizes are difficult to find, at least in a list form. At one time, all manufacturers went to the trouble to do so with printed brochures but now, with the internet, not so much.

With the move to EOS R cameras and the highly capable and versatile EF-RF adaptors, the older EF lenses remain hugely popular. Indeed, with focusing accuracy as good if not better than the older DSLRs, especially when focused off-centre, EF lenses have seen a new lease of life.

Filters for lens protection seem to divide opinions, however, I’m strongly in favour of them. Not only do they prevent fumbling with lens caps (keep those for storage), but they’re also a lot easier to clean than the front element. Damage the filter, and it’s easy to replace. Damage the lens, and that’s a real problem. Get it fixed? Sell it? Buy another? I know what I prefer.

For Canon lenses, I recommend Canon regular ‘Protect’ or Protector filters as they’re extremely high quality. They’re also very reasonably priced, at least for the popular sizes.  Above 82mm, though, and they start to get pricey. The 95mm is pretty steep, for example, so you could look for more competitive offerings, such as the Firecrest models for that and larger. They make protector and UV types. In my experience, there’s not much between them, even protectors reduce UV, so it depends on how fussy you are. If you want consistent colour, there’s an argument to standardise and buy the same type, but that’s probably more of an issue for videomakers than stills photographers.   [affiliate links follow]:

Canon UK Store

Canon US Store

Amazon UK (Canon Protect) | Amazon UK (Formatt Hitech – Firecrest)

Amazon US (Canon Protect)  | Amazon US (Formatt Hitech – Firecrest)

As an Amazon Associate, I earn from qualifying purchases. Please also use the links for the hoods and cases. Thank you for being so supportive.

The following is a work in progress, the columns will be filled out in due course [Amazon affiliate links]

Focal Length
Fixed  Filter Thread Hood Case
EF 14mm F2.8L II USM Rear Insert Built-in LP1016
EF 15mm F2.8 Fisheye Rear Insert Built-in LP814
TS-E 17mm F4L n/a n/a LP1219
EF 20mm F2.8 USM 72mm EW75II LP1214
EF 24mm F1.4L USM 77mm EW-83DII LP1214
EF 24mm F1.4L II USM 77mm EW-83K LP1214
TS-E 24mm F3.5L 72mm EW-75BII LP1216
TS-E 24mm F3.5L II 82mm EW-88B LP1319
EF 24mm F2.8 IS USM 58mm EW-65B LP1014
EF 28mm F1.8 USM 58mm EW-65II LP814
EF 35mm F1.4L USM 72mm EW-73F LP1214
EF 35mm F1.4L II USM 72mm EW-77B LP1219
EF 35mm F2 IS USM 67mm
TS-E 45mm F2.8 72mm EW-79BII LP1216
EF 50mm F1.0L USM 72mm ES-76 LP1219
EF 50mm F1.2L USM 72mm ES-78 LP1214
EF 50mm F1.4 USM 58mm LP1014
EF 50mm F1.8 II 52mm LP1014
EF 50mm F2.5 Compact Macro 52mm Built-in LP814
TS-E 50mm F2.8L Macro 77mm Es-84 LP1219
MP-E 65mm F2.8 1-5X Macro 58mm MP-E65 LP1216
EF 85mm F1.2L USM 72mm ESS-79II LP1219
EF 85mm F1.2L II USM 72mm ES-79II LP1219
EF 85mm F1.4L USM 77mm ET-83E LP1219
EF 85mm F1.8 USM 58mm ET-65III LP1014
TS-E 90mm F2.8 58mm ES-65III LP1016
TS-E 90mm F2.8L Macro 77mm ES-84 LP1219
EF 100mm F2 USM 58mm ET-65III LP1014
EF 100mm F2.8L Macro IS USM 67mm ET-73 LP1219
EF 135mm F2L USM 72mm LP1219
TS-E 135mm F24L Macro 82mm ET-88 LP1424
EF 180mm F3.5L Macro USM 72mm ET-78II LZ1324
EF 200mm F2.8L II USM 72mm
EF 300mm F2.8L IS II USM 52mm (Drop-In)
EF 300mm F4L IS USM 77mm
EF 400mm F2.8L IS II USM 52mm (Drop-In)
EF 400mm F4L DO IS USM 52mm (Drop-In)
EF 400mm F5.6L IS USM 77mm
EF 500mm F4L IS USM 52mm (Drop-In)
EF 600mm F4L IS USM 52mm (Drop-In)
EF 800mm F5.6L IS USM 52mm (Drop-In)
EF 1200mm F8L IS USM 48mm (Drop-In)
Zoom
EF-S 10-22mm F3.5-4.5 USM 77mm EW-83E LP1319
EF-S 17-85mm F4-5.6 IS USM 67mm
EF-S 18-55mm F3.5-5.6 USM 58mm
EF-S 18-55mm F3.5-5.6 58mm
EF 11-24mm F4L USM Rear Insert n/a LP1424
EF 16-35mm F2.8L USM 77mm EW-83E LP1319
EF 16-35mm F2.8L II USM 82mm EW-88 LP1319
EF 16-35mm F2.8L III USM 82mm EW-88D LP1319
EF 16-35mm F4L IS USM 77mm EW-82 LP1219
EF 17-40mm F4L USM 77mm EW-83E LP1319
EF 24-70mm F2.8L USM 77mm EW-83F LP1219
EF 24-70mm F2.8L II USM 82mm EW-88C LP1219
EF 24-70mm F4L IS USM 77mm EW-83M LP1219
EF 24-105mm F4L IS USM 77mm
EF 24-105mm F4L IS II USM 77mm EW-83M LP1219
EF 24-105mm F3.5-5.6 IS STM 77mm EW-83M LP1219
EF 28-300mm F3.5-5.6L IS USM 77mm EW-83G LZ1324
EF 70-200mm F2.8L IS USM 77mm ET-86 LZ1324
EF 70-200mm F2.8L IS II USM 77mm ET-87 LZ1326
EF 70-200mm F2.8L IS III USM 77mm ET-87 LZ1326
EF 100-300mm F2.8L IS USM 112mm
EF 100-400mm F4.5-5.6L IS II USM 77mm ET-83D LZ1326
EF 100-500mm F4.5-7.1L IS USM 77mm
EF 200-400mm F4L IS USM Extender 1.4x  52mm (Drop-In) ET-120 (WII) Case 200-400
